很多在超聲波清洗機設備上都有脫氣，那么這個到底是什么原理和功能，下面就為大家解答：

Many of them are available on ultrasonic cleaning machines. So what is the principle and function of this, here are the answers:

當超聲波進入溶液時，會產生交變壓力。用于空化閾值的聲波在液體中傳播時會產生空化氣泡，能顯著提高氣體從溶液到氣泡的傳質速率。空化氣泡是由溶液中的微小氣核產生的，這些氣核是由聲波稀相的拉應力（負壓）產生的。

When ultrasonic wave enters the solution, alternating pressure will be generated. The cavitation bubble will be produced when the acoustic wave used for cavitation threshold propagates in liquid, which can significantly improve the mass transfer rate of gas from solution to bubble. Cavitation bubbles are produced by the tiny gas cores in the solution, which are produced by the tensile stress (negative pressure) of the dilute phase of sound waves.

如果在空化形成后拉伸應力仍然存在，時空氣泡將膨脹到其初始尺寸的許多倍。在這種情況下，空化氣泡保持球形，然后增長、振動和塌陷。當超聲波作用時，溶液中的氣體成分可以通過氣液界面的“定向擴散”進入空化泡，空化泡進入人的生長階段。當空化氣泡在溶液表面塌陷時，氣體會從氣泡中逸出，從而引起脫氣。

If the tensile stress still exists after cavitation, the bubble will expand to many times its initial size. In this case, the cavitation bubble remains spherical, then grows, vibrates and collapses. When ultrasonic is applied, the gas components in the solution can enter into cavitation bubbles through the "directional diffusion" of the gas-liquid interface, and the cavitation bubbles enter the growth stage of human beings. When the cavitation bubble collapses on the surface of the solution, the gas will escape from the bubble, which will cause degassing.

超聲波脫氣設備的優點是，泡沫是大量氣泡聚集而成，超聲波脫氣設備是在泡沫形成的早期，氣泡不是大量積聚的液體消泡、除氣，或者溶解，混合在液體氣體中消泡、除氣。整個過程不使用任何消泡劑，完全是物理消泡，也可以稱為機械消泡。對于已經產生的表面泡沫，該裝置沒有明顯的效果，需要用消泡膜來解決。

The advantage of the ultrasonic degassing equipment is that the bubbles are gathered by a large number of bubbles. The ultrasonic degassing equipment is in the early stage of the bubble formation. The bubbles are not a large number of accumulated liquid defoaming, degassing, or dissolving, and are mixed in liquid gas to defoaming and degassing. The whole process does not use any defoaming agent, it is completely physical defoaming, also can be called mechanical defoaming. For the surface foam that has been produced, the device has no obvious effect and needs to be solved by the antifoaming film.

脫氣主要采用超聲波“定向擴散”，一旦空化發生，內部仍有空氣，在一些熔融液體脫氣凈化應用中不產生空化。排出液體空氣，降低超聲波空化反應產生氣泡的阻力，提高超聲波清洗機的清洗效率。另一個影響是超聲波清洗機工作時間長了會產生一種超聲波疲勞，降低清洗效果和效率，排氧氣功也能消除這種超聲波疲勞。

Degassing mainly adopts ultrasonic "directional diffusion", once cavitation occurs, there is still air inside, and there is no cavitation in some degassing and purification applications of molten liquid. The liquid air is discharged, the resistance of bubbles produced by ultrasonic cavitation reaction is reduced, and the cleaning efficiency of ultrasonic cleaning machine is improved. Another effect is that the ultrasonic cleaning machine will produce a kind of ultrasonic fatigue after working for a long time, which can reduce the cleaning effect and efficiency, and the oxygen exhaust gas can also eliminate this kind of ultrasonic fatigue.

綜上所述，可以看出超聲波清洗設備的非常強大，可以更好地達到清洗的目的，提高清洗效果。

In conclusion, it can be seen that the ultrasonic cleaning equipment is very powerful, and can better achieve the purpose of cleaning and improve the cleaning effect.

產品特點：

Product features:

與傳統產品相比，堅持靜音設計，降低噪音，提高功率轉換，延長使用壽命。

Compared with traditional products, we should adhere to silent design, reduce noise, improve power conversion and extend service life.

元黑色鋼化玻璃觸摸屏控制，超質感，控制鍵簡單清晰。

The touch screen control of meta black tempered glass, super texture, simple and clear control key.

水晶珠銀烤漆外殼，易清洗，永遠新。

Crystal Bead Silver baking paint shell, easy to clean, forever new.

目的：

Objective: To study the effect of the method on the development of the system

清洗、消毒、滅菌、脫氣、乳化、混合、置換、萃取、粉碎等。

Cleaning, disinfection, sterilization, degassing, emulsification, mixing, replacement, extraction, grinding, etc.

使用范圍：

Scope of use:

主要用于電子、機械、光學、珠寶、蒸汽保險、醫藥、電鍍、鍍膜及真空鍍膜預處理等行業。特別適用于表面形狀復雜的零件，如清洗工件上的狹縫、溝槽、深孔、盲孔等。同時可以清洗零件表面的油污、鐵銹和氧化物。真正做到清潔、消毒、滅菌。

It is mainly used in electronic, mechanical, optical, jewelry, steam insurance, medicine, electroplating, coating and vacuum coating pretreatment. It is especially suitable for parts with complex surface shape, such as cleaning the slit, groove, deep hole and blind hole on the workpiece. At the same time, the oil, rust and oxide on the surface of parts can be cleaned. Truly clean, sterilize and sterilize.

功能和特點：

Functions and features:

1、與傳統產品相比，噪音降低30%以上，超聲波功率轉換效率提高30%以上，清洗速度快，使用壽命長。

1. Compared with traditional products, noise is reduced by more than 30%, ultrasonic power conversion efficiency is increased by more than 30%, cleaning speed is fast and service life is long.

2、產品設計美觀大方，外殼采用優質不銹鋼壓花板，防銹性能好；清洗槽采用優質SUS304不銹鋼沖壓成型，無焊接處，防水性能好；3、產品清洗溫度可在設計范圍內任意調節，工作時間可數字控制

2. The product is designed with beautiful and generous appearance, and the shell adopts high-quality stainless steel embossing board, which has good rust resistance performance; the cleaning tank is made of high-quality SUS304 stainless steel stamping, without welding place, and has good waterproof performance; 3. The product cleaning temperature can be adjusted arbitrarily within the design scope and the working time can be controlled digitally

4、LED數顯可任意調節1-99分鐘，滿足不同清洗要求；

4. LED digital display can be adjusted for 1-99 minutes at any time to meet different cleaning requirements;

5、6L及以上規格設有快速排放廢液的排放裝置；

5. 6L and above specifications are equipped with a discharge device for rapid waste liquid discharge;

6、SUS304專用清洗籃可選；

6. SUS304 special cleaning basket is optional;

7、采用優質進口核心部件，使用壽命長；

7. Adopt high quality imported core parts, long service life;

8、清洗物體時，不需要人工接觸清洗液和攪拌工件。工件表面無損傷，安全可靠。清洗工件時，可節省溶劑、熱能、工作場所和人工。

8. When cleaning objects, it is not necessary to contact the cleaning solution and stir the workpiece manually. The surface of the workpiece is free of damage and is safe and reliable. When cleaning the workpiece, it can save solvent, heat, workplace and labor.
